W9 Series — Lane Ends / Divided Highway Warning Signs

The W9 Series includes warning signs for lane-ending and divided-highway transitions. W9-2 (LANE ENDS) is widely used in California work zones at the downstream end of a lane reduction taper to reinforce the merge for drivers who missed the upstream W20-5 series advance warning. It is also used at permanent lane drops. W9 signs complement the W4 and W20-5 series in lane-closure sequences.

5

Signs in W9

4

Download Formats

Updated

Per Latest MUTCD

Series

Sign Code

Category

Showing 1–5 of 5 W9 Series Signs

Sort by

W9-1 Right (Left) Lane Ends — official FHWA layout

Right (Left) Lane Ends

W9-2 Lane Ends Merge Left (Right) — official FHWA layout

Lane Ends Merge Left (Right)

W9-2a Merge Here Take Turns — official FHWA layout

Merge Here Take Turns

W9-3 Interior Lane Shift Ahead — official FHWA layout

Interior Lane Shift Ahead

W9-5a Bicycles Merging — official FHWA layout

Bicycles Merging
