G20 Series — End of Work Zone / Road Work Guide Signs
Guide Signs · CA MUTCD Part 6, Chapter 6F
The G20 Series marks the downstream end of a temporary traffic control zone, signaling to drivers that normal roadway conditions have resumed and work zone speed limits and restrictions no longer apply. G20-1 (END ROAD WORK) and G20-2 (END CONSTRUCTION) are the standard terminal signs for California TCPs. They are placed at the downstream end of the termination area, just past the last channelizing device or transition.
California Field Use Notes
G20-1 or G20-2 is required at the end of every work zone. Its absence is a common plan-review deficiency. Some agencies prefer G20-1 for short-duration work and G20-2 for longer construction projects, though both are acceptable under the CA MUTCD. When a reduced speed zone ends, the G20 sign reinstates normal speed.
Showing 4 of 4 signs
Informs drivers of the total length of a work zone, telling them how many miles of road work to expect ahead.
Marks the downstream end of a work zone, informing drivers that they have passed the work area and that normal conditions resume.
The G20-4 Pilot Car Follow Me sign is a California MUTCD work zone guide sign. It is shown here as an educational reference with the official FHWA Standard Highway Signs layout and California sizing guidance.
The G20-5aP Work Zone (plaque) sign is a California MUTCD work zone guide sign. It is shown here as an educational reference with the official FHWA Standard Highway Signs layout and California sizing guidance.
Educational reference only. This is not an official Caltrans, FHWA, or local agency publication and is not legal or engineering advice. Always verify sign selection, size, placement, spacing, and application against the current CA MUTCD 2026, Caltrans sign specifications, Standard Plans, project documents, and the reviewing agency’s requirements.
